Strain Tower
Our Strain Towers provide durable support for transmission lines at directional changes or elevated points. Built with high-strength steel, they are optimized for tension control, corrosion resistance, and long-term performance, ensuring network stability.
- Service Type: Strain Tower Design, Fabrication, and Installation
- Material Expertise: High-grade steel (Q235, Q355, Q420)
- Design Standards: ISO 9001:2015, AWS D1.1
- Surface Treatment: Hot-Dip Galvanizing (ASTM A123)
- Applications: High-voltage transmission lines, industrial power grids, and renewable energy transmission
Overview
Our Strain Towers, also known as angle or tension towers, are designed to handle high mechanical stress caused by changes in line direction or elevation. Constructed with high-strength steel and optimized for durability, these towers prevent excessive tension and maintain structural stability in high-voltage and low-voltage transmission networks. With corrosion-resistant coatings and customizable configurations, they are ideal for power grids, industrial power transmission, and renewable energy projects. We offer end-to-end services, including design, fabrication, installation, and maintenance.
- High Mechanical Strength: Designed to handle high tension forces caused by line direction changes.
- Durable Steel Construction: Built using high-strength steel for enhanced stability and load-bearing capacity.
- Wind and Seismic Resistance: Engineered to withstand high winds, seismic activity, and other environmental stresses.
- Corrosion Protection: Hot-dip galvanized coating provides long-lasting protection against rust and environmental wear.
- Customizable Configurations: Available in different heights, voltages, and configurations to meet project-specific requirements.
- Optimized Load Distribution: Efficient design evenly distributes tension to minimize structural stress.
- Quick and Efficient Installation: Pre-fabricated components simplify on-site assembly, reducing construction time and costs.
- High-Voltage Transmission: Providing support at angles and elevation changes for regional and national power grids.
- Renewable Energy Projects: Supporting wind, solar, and hydropower transmission lines.
- Industrial Power Distribution: Ensuring stable and efficient power delivery to industrial zones and plants.
Our Strain Towers undergo comprehensive inspections during design, fabrication, and installation, ensuring compliance with international standards for safety, performance, and reliability.
Feature
Long-Lasting and Reliable Performance:
Constructed using high-strength steel and corrosion-resistant coatings, our towers are designed to withstand environmental stresses such as high winds, heavy rain, and temperature variations. Their reliable design ensures more than 30 years of service.
Optimized for High Tension and Stability:
Strain Towers are optimized to manage mechanical stress at angles and changes in terrain. The design distributes the load efficiently, preventing structural fatigue and ensuring long-term network stability.
Safety and Compliance Focused:
We adhere to ISO9001:2015, AWS D1.1, and other international safety standards, ensuring maximum structural security and performance. Built-in safety features include secure mounting, grounding, and lightning protection.
Efficient Installation and Maintenance:
Pre-fabricated modular components allow for quick on-site assembly, reducing project timelines and costs. The towers are designed for easy access, enabling efficient maintenance and upgrades as needed.
Specification
| Details | Additional Information |
|---|---|
| Brand: Xiangyue (XY Tower) | Height Options: Customizable from 10m to 120m based on voltage and project needs |
| Service Offering: Strain Tower Design, Fabrication, and Installation | Environmental Adaptability: Suitable for high winds, seismic zones, and extreme weather conditions |
| Expertise: Specialized in designing strain and tension towers for power grids and industrial networks | Load Capacity: Designed to support high-tension conductors, cables, and insulators |
| Design Standards: Adheres to ISO9001:2015, AWS D1.1, and relevant industry standards | Certification: Meets international safety, quality, and structural certifications |
| Material Specification: High-grade steel, including Q235, Q355, and Q420 | Customization Level: Fully tailored to meet project-specific and site-specific requirements |
| Welding Standard: Certified AWS D1.1 welding procedures | Installation Assistance: Provides on-site guidance and modular assembly instructions |
| Surface Treatment: Hot-Dip Galvanizing and protective coatings for corrosion resistance | Global Reach: Serving clients worldwide with tailored solutions for local regulations |
| Quality Control: Comprehensive inspections during design, production, and installation | Post-Design Support: Ongoing maintenance, upgrade services, and technical support |
